Schiavi LineAr 220.50 press brake
The Schiavi LineAr 220.50 is a hydraulic press brake with 220 t of pressing force and a 5,200 mm bending length.
Specifications
| Drive System | Hydraulic |
|---|---|
| Bending length | 5,200 mm |
| Pressing force | 220 t |
| Distance between side frames | 4,700 mm |
| Maximum opening | 400 mm |
| Maximum stroke | 220 mm |
| Throat depth | 420 mm |
| Closing speed | 110 mm/s |
| Maximum working speed | 10 mm/s |
| Return speed | 100 mm/s |
Not published by Schiavi for this model: Synchronisation, CNC controller, Frame type.
Where these figures come from
Read from the specification table in Schiavi’s PDF at schiavimacchine.it (model “220.50”) on 28 October 2026. Values are copied cell by cell and never estimated; force given in kN is divided by 10 for tonnes; a published range is shown by its upper value.
