Schiavi BSTS 125.30 press brake
The Schiavi BSTS 125.30 is a hydraulic press brake with 125 t of pressing force and a 3,140 mm bending length.
Specifications
| Drive System | Hydraulic |
|---|---|
| Bending length | 3,140 mm |
| Pressing force | 125 t |
| Distance between side frames | 2,700 mm |
| Maximum opening | 400 mm |
| Maximum stroke | 200 mm |
| Throat depth | 420 mm |
| Closing speed | 200 mm/s |
| Maximum working speed | 10 mm/s |
| Return speed | 90 mm/s |
Not published by Schiavi for this model: Synchronisation, CNC controller, Frame type.
Where these figures come from
Read from the specification table in Schiavi’s PDF at schiavimacchine.it (model “125.30”) on 28 October 2026. Values are copied cell by cell and never estimated; force given in kN is divided by 10 for tonnes; a published range is shown by its upper value.
Similar machines from other makers
Within 15% of the pressing force and 10% of the bending length.
