Schiavi HFBX 80.20 press brake
The Schiavi HFBX 80.20 is a hybrid press brake with 80 t of pressing force and a 2,090 mm bending length.
Specifications
| Drive System | Hybrid |
|---|---|
| Bending length | 2,090 mm |
| Pressing force | 80 t |
| Distance between side frames | 1,660 mm |
| Maximum opening | 600 mm |
| Maximum stroke | 365 mm |
| Throat depth | 405 mm |
| Closing speed | 220 mm/s |
| Maximum working speed | 10 mm/s |
| Return speed | 200 mm/s |
Not published by Schiavi for this model: Synchronisation, CNC controller, Frame type.
Where these figures come from
Read from the specification table in Schiavi’s PDF at schiavimacchine.it (model “80.20”) on 28 October 2026. Values are copied cell by cell and never estimated; force given in kN is divided by 10 for tonnes; a published range is shown by its upper value.
Similar machines from other makers
Within 15% of the pressing force and 10% of the bending length.
