Schiavi HFBS 170.40 press brake
The Schiavi HFBS 170.40 is a hybrid press brake with 170 t of pressing force and a 4,230 mm bending length.
Specifications
| Drive System | Hybrid |
|---|---|
| Bending length | 4,230 mm |
| Pressing force | 170 t |
| Distance between side frames | 3,760 mm |
| Maximum opening | 500 mm |
| Maximum stroke | 250 mm |
| Throat depth | 420 mm |
| Closing speed | 200 mm/s |
| Maximum working speed | 10 mm/s |
| Return speed | 200 mm/s |
Not published by Schiavi for this model: Synchronisation, CNC controller, Frame type.
Where these figures come from
Read from the specification table in Schiavi’s PDF at schiavimacchine.it (model “170.40”) on 28 October 2026. Values are copied cell by cell and never estimated; force given in kN is divided by 10 for tonnes; a published range is shown by its upper value.
