Murata Machinery BB306 press brake
The Murata Machinery BB306 is an electric press brake with 28 t of pressing force and a 630 mm bending length.
Specifications
| Drive System | Electric |
|---|---|
| CNC controller | MOS (Muratec Operating System) |
| Bending length | 630 mm |
| Pressing force | 28 t |
| Distance between side frames | 700 mm |
| Maximum opening | 280 mm |
| Maximum stroke | 150 mm |
| Throat depth | 200 mm |
| Closing speed | 95 mm/s |
| Maximum working speed | 20 mm/s |
| Return speed | 95 mm/s |
Not published by Murata Machinery for this model: Synchronisation, Frame type.
In Murata Machinery’s words
“It is equipped with the newly developed MOS (Muratec Operating System), which has a completely redesigned UI (user interface).”
Where these figures come from
Read from the specification table in Murata Machinery’s PDF at muratecbrasil.com.br (model “BB306”) on 28 October 2026. Values are copied cell by cell and never estimated; a published range is shown by its upper value.
