CoastOne Cone G20 press brake
The CoastOne Cone G20 is an electric press brake with 60 t of pressing force and a 2,040 mm bending length.
Specifications
| Drive System | Electric |
|---|---|
| Bending length | 2,040 mm |
| Pressing force | 60 t |
| Distance between side frames | 2,200 mm |
| Maximum opening | 600 mm |
| Maximum stroke | 280 mm |
| Closing speed | 100 mm/s |
| Maximum working speed | 10 mm/s |
| Return speed | 100 mm/s |
Not published by CoastOne for this model: Synchronisation, CNC controller, Frame type, Throat depth.
Where these figures come from
Read from the specification picture on CoastOne’s product page at coastone.fi (model “Cone G20”) on 28 October 2026. Values are copied cell by cell and never estimated; Published as kN with US tons in brackets, e.g. 440(49); the kN figure is read.; force given in kN is divided by 10 for tonnes; Published as 10 (20*): 10 mm/s, with the footnote "*can be up to 20mm/s, depending on regulations"; the first figure is read..
Similar machines from other makers
Within 15% of the pressing force and 10% of the bending length.
