Gizelis G FLEX ® 3175 press brake
The Gizelis G FLEX ® 3175 is a hydraulic press brake with 175 t of pressing force and a 3,100 mm bending length.
Specifications
| Drive System | Hydraulic |
|---|---|
| CNC controller | CybTouch12 |
| Bending length | 3,100 mm |
| Pressing force | 175 t |
| Distance between side frames | 2,550 mm |
| Maximum opening | 515 mm |
| Maximum stroke | 250 mm |
| Throat depth | 400 mm |
| Closing speed | 160 mm/s |
| Maximum working speed | 20 mm/s |
| Return speed | 140 mm/s |
Not published by Gizelis for this model: Synchronisation, Frame type.
In Gizelis’s words
“2D graphic controller, 12” color Touch-Screen, CybTouch12”
Where these figures come from
Read from the specification table in Gizelis’s PDF at gizelis.com (model “G FLEX ® 3175”) on 28 October 2026. Values are copied cell by cell and never estimated; a published range is shown by its upper value.
Similar machines from other makers
Within 15% of the pressing force and 10% of the bending length.
